Honda HF2317HM Ride-On Mower

New for the 2020 season and equipped with a new Euro 5 compliant engine, this product is one of the latest generation Honda lawn tractor models.

Product Overview:

  • Cutter Deck Size: 92cm
  • Garden Size: Very Large. Suitable for lawns up to 5,000m² (1.25 acres)
  • Transmission: Variable Hydrostatic Drive – This lawnmower’s speed is adjusted by pedal control
  • Mulching: Optional – Mulching is only available on this model if you purchase an additional mulching kit from a Honda Dealer
  • Grass Bag Capacity: 280L
  • Grass Bag Dumping: Manual – Dispose of grass clippings by lifting a lever
  • Soft Grip Steering and Colour LDC Display: Not available
  • Speed Hold: Not available
  • USB Charging and Device Holder: Not available

Email when stock available

Product Information

HONDA HF2317HM RIDE-ON MOWER

Several new features have been developed for the Honda HF2317HM Ride-on Mower, with enhanced convenience and comfort in mind. The latest innovations include a full colour LCD display, a Speed Hold System and USB charging so choose your model based on your requirements.

Optiflow™

A fan powered system under the cutter deck that improves air flow between the cutter deck and the high air flow grass bag. It significantly improves collecting performance of the lawnmower.

Function
Blade brake clutch Electromagnetic
Optiflow Yes
Grass bag dumping Manual
Positions and cutting 7
Noise value - sound power level (dB(A)) 100
Mulching Optional
Rear deflector Optional
Tow hitch Optional
Dimensions
Length (mm) 2440
Width (mm) 970
Height (mm) 1230
Dry weight (kg) 218
Cutting
Cutter deck size (cm) 92
Number of blades 2
Synchro or Asynchro Asynchronous
height adjustment (mm) 30 - 80
Grass bag capacity (Litres) 280
Engine
Engine OHC V-twin 4-stroke
Engine displacement (cc) 530
Engine model GCV 530
Engine Rated Power (kW/rpm) 9.7/2800
Fuel tank capacity (Litres) 5.4
Engine oil capacity (Litres) 1.3
Transmission type Variable: Hydrostatic
Driving speed (km/h) Progressive 0 to 8.2
Tyres
Front tyres (diameter x width - rim) (inches) 13 x 5.00 - 6
Rear tyres (diameter x width - rim) (inches) 18 x 8.50 - 8
Turning radius (m) 1.8

Unrivalled Warranty

Honda's products are built better to last longer. That’s why you are offered a rock-solid warranty for domestic and professional use on Honda's core range products, covering both parts and labour.

The warranty also maintains the same value throughout the warranty period – meaning the last day of cover is exactly the same as the first.

*Subject to domestic use and following the service schedule.

Want to see more?

See more from Honda's range of lawnmowers here.

Get more information about their lawnmower range from their brochure.
