Kubota M5001 Narrow Tractor

A slender worker

The Kubota Narrow tractor series is now even better than before, offering up to 108 engine horsepower, greatly enhanced ergonomics and many value-add features. Kubota engineered the M5001N specifically for work in orchards, soft fruit production and vineyards, or any other environments that might require a narrow tractor. It also features a new high/low powershift transmission with 6 synchronised gears and an extra powerful engine, new to the market. The Kubota M5001N Series tractors are particularly convenient and ideally suited for orchard, vine and fruit cultivation.
Categories: , ,

Product Information

KUBOTA M5001 NARROW TRACTOR

ENGINE

Performance you can rely on

A strong heart beats under the bonnet of the Kubota M5001 Narrow Tractor. The new V-3800 TIE 4F 4-cylinder engine with 3B emission level provides 73 HP – 105 HP (according to 97/68 EC).

With an extra kick of power

The M5071N has a sizeable 3.8 l engine under the bonnet – which is unique in this horsepower class, and gives the model the right power for all jobs.

Clean technology

The diesel particulate filter in the new engine reliably reduces emissions. The two electronic engine settings provide convenient quick adjustments for repetitive work. Which is not only useful, but also saves time.

Convenient speed monitoring

The engines also have a new electronic speed control with which you can control the speed of the engine. Once the RPM mode system has been activated, the speed remains constant, even when the demand for power varies. As a result, PTO-driven implements can be run with constant efficiency.

New fuel tank

Instead of three tanks, like its predecessors, it has only two large tanks on the bottom side of the cab. This provides not only more capacity and thus longer usage times, but also higher tank comfort. The new tank design gives you better visibility towards the rear, as a rear tank is not required. And since there are two tanks instead of three, the fuel gauge is also more accurate.

DRIVELINE

Smooth gear shifting even under harsh conditions

With the Kubota M5001 narrow tractor series, you can choose between two type of transmissions: one transmission with 18 forward and reverse gears and a comfort transmission with 36 forward and reverse gears with dual-speed powershift speeds. With great efficiency at low and high speeds, the finely harmonized and smooth shifting transmissions stand for shifting pleasure, reliability and economy. Another improvement is the non clutch button as standard feature on the 36/36 gearbox, the non clutch button supports the operators comfort with easy gear shifting, just press the button and shift among the 6 gears.

Lightning fast gear shifting with loads

The dual-speed technology of the 36F/36R transmission enables lightning-fast upshifting and downshifting. With increasing load in the Hi position, you simply press the Dual Speed button on the shift lever. The driving speed is then reduced and the torque increased.

Driving fast and saving fuel

The overdrive function of the transmission keeps the en-gine speed low when driving at high speeds. The 40-ECO transmission gets you to your destination quickly while at the same time saving fuel and reducing the noise level.

Easy change of direction

Thanks to the electro-hydraulic shuttle lever of the M5001N, you can change direction quickly and easily without using the clutch. You simply have to move the electro hydraulic shuttle lever forward or backward.

CAB

Your command centre for long working days

Big, very spacious, with perfect ergonomics – the comfortable flat floor cab of the Kubota M5001 narrow tractor provides all the prerequisites for pleasant and productive work. In that way, you can fully concentrate on your job and achieve the best results, without having to make any compromises in terms of comfort.

The steering wheel – an all-round success

The M5001N’s handy steering wheel can be tilted by 40°. When getting out, you simply tilt it forward. And when you sit back in your seat, you can quickly bring it back into the original position. The level cab floor makes getting in and out even easier. The steering wheel angle has been optimized by Kubota – one of several intelligent innovations in the cab.

Optimal control and operation

Speaking of the dashboard: Kubota’s multifunctional Intellipanel, with multiple views and excellently readable LCD display, provides you with all important operating data and functions at a glance. All important controls are located on the right side of the driver’s seat – easy to reach and ergonomically positioned for safe operation.

Rounded windows

In order to give you an even better view on all sides, Kubota has rounded the cab windows. A positive side effect of this new feature: The cab of the M5001N feels even bigger than it already is. Furthermore, reflections are reduced. And Kubota has also increased the glass area of the cab door, which makes getting in and out of the cab even easier.

Pleasant climate at all times

The standard air conditioning and powerful heating system of the M5001N ensure pleasant temperatures in the cab in all seasons.

ROPS

For unobstructed views

The M5001N is also available as a DTH version with roll bar. The advantages of these cab-free tractors are obvious: unimpeded access to and from the vehicle, as well as a perfect view of the implements and the area and culture that is being worked on.

Simple handling of roll bar

The position of the roll bar can be conveniently fold out or in – which is practical if a lower height is required, for example at low building entrances. You can fold in the roll bar simply and effortlessly with two easily accessible pins. You merely have to loosen the pins, just adjust the bar and fix it again – done!

Ideal ergonomics and water-resistance

The control elements of the DTH models are conveniently located on the right side next to the driver’s seat. All switches and levers are ergonomically optimized and are particularly comfortable to operate. The new dashboard of the tractor is designed to give you an unobstructed view ahead. Since tractor work does not come with a fair-weather guarantee, all instruments and controls are, of course, absolutely watertight. Even heavy downpours will not cause any problems.

HYDRAULICS/LINKAGE/CONNECTIVITY

The M5001N lifts heavy loads with ease

More power and performance for all tasks is the motto for the lift linkage of the M5001N. Thanks to its stable category II 3 point hitch, the tractor can lift heavy equipment with ease. 2,300 kg lifting capacity speak for themselves. You will really appreciate the additional lifting capacity in areas where your previous tractor reached its limits

Increased flexibility of hydraulics

When it comes to the hydraulic system, the cab version of the M5001N gives you a choice. You have the option of extending the number of hydraulic connections on the front and rear of the tractor from the standard two to five. Five hydraulic connections with flow control enable you to carry out various tasks at the same time with a single implement using up to five control units – which greatly simplifies even the most demanding tasks. Kubota has also provided the M5001N with a stronger hydraulic pump. The increased capacity of up to 69 l/min for the M5101 cab model is the basis for increased productivity and performance.

Electro hydraulic PTO

The independent 540/540E PTO comes as standard and can be turned on or off at the switch of a button. A 1000 PTO speed shaft is also optionally available. The PTO engages itself in a self-modulating fashion so that even heavy equipment runs smoothly. If you switch off the rear PTO, the PTO shaft brake is activated automatically and the implements stop safely. The operator can activate the ECO PTO speed which automatically sets the engine speed revolution to the right rpm value in order to protect any damage on the PTO line.

MANEUVERABILITY

The front axle with bevel gear drive and a steering angle of an astounding 55° give the M5001N unique agility. This makes the tractor ideal for jobs in tight spaces.

Soft, soil-preserving turning

The “bi-speed turn”, provided only by Kubota, makes turning even easier. If the steering angle of the front wheels exceeds a value of 35°, when using all-wheel drive, the speed of the front wheels almost doubles compared to the rear wheels. This results in softer and tighter turning that is particularly gentle on the ground. You’ve got the choice of working with or without “bi-speed turns”.

High ground clearance and driving stability

It’s front axle also gives the M5001N high ground clearance that is among the best in its class. This is particularly useful when dealing with permanent crops such as fruit and wine, where sawn wood in the rows is no longer an obstacle. The 80 mm longer wheelbase provides additional stability as well as more comfort when driving the tractor. Adjustable overall width from 1.250 mm to 1.940 mm ensures safe working in steep terrain.

All-wheel drive easily turned on and off

The all-wheel drive is engaged and disengaged with the simple press of a button. And the best part is that the tractor doesn’t even have to be stopped, even when switching from the field to the road. This helps you stay productive, and an LED indicator shows you the current status.

No chance of slippage

The limited slip differential on the front axle and the differential lock on the rear axle come as standard with the Kubota M5001 narrow tractor . They provide increased stability and traction as well as a smooth ride in challenging soil and terrain conditions, even in the case of slippage.

KUBOTA FARM SOLUTIONS SECTION

360° PERFORMANCE FOR 100% SUCCESS
PERFORMANCE
The M5001N is a highly productive professional vehicle for demanding tasks. In orchards, fruit cultivation and vineyards. It delivers the highest levels of agility, versatility and performance.
CONTROL
With the optional IsoMatch Tellus monitors, you can turn your M5001N into an ISOBUS control tractor. You can take your work to a new level of efficiency ,saving time and resources, and therefore money
OPTIMISATION
Retrofit kits make the M5001N fit for Precision Farming. Take advantage of the many possibilities offered by this state-of-the-art technology for the efficient and environmentally friendly management of your land.
VALUE PROTECTION
Kubota tractors offer proven quality and excellent performance. Kubota offers you a two-year warranty on the M5001N, which you can opt to extend to five years with the Kubota Care package.
FINANCE MANAGEMENT
The M5001N stands for productivity and efficiency in your work With Kubota Finance, you can invest in technology that will make an important contribution to your business. Bespoke finance packages allow you to tailor payment options to suit your business needs.

Agricultural Tractors By Kubota Offer Comfort With Utility

Designed with a life cycle of constant work in mind, few agricultural tractor ranges offer the level of durability that Kubota’s does. Every Kubota tractor is made to the highest standards of production to ensure that the farm equipment will function as it should many years after it has been first put to work. Of course, this all begins at the design stage when Kubota's expert engineers get to work conceptualising utility tractors and other forms of agricultural machinery that will last. Indeed, agricultural tractors like Kubota’s are not just there to be reliable. They are designed with agricultural needs in mind, in other words to help you to work more effectively and to improve yields year after year.

Kubota’s versatile and intelligent agricultural tractors instantly appeal because of their high performance even when they are working on different types of ground. Farmers who have used Kubota's agricultural equipment before constantly report that their tractors offer unbeatable value for money well into their life cycles. Each agricultural tractor is designed and manufactured using the most modern production techniques to reduce onward operational costs, to provide remarkable versatility in the field as well as two other key ingredients, maneuverability and agility.

Agricultural Tractors Which Aim to Deliver

There is lots of choice within the agricultural tractor range of machines but each of the models have certain things in common. And it does not just come down to the distinctive orange and black look of Kubota's tractors either! Firstly, the highly powered engines that are fitted into their tractor range are extremely respectful of the environment and designed to be as fuel efficient as possible given the workload these precisely engineered machines will need to cope with. Kubota ensure that they are able to meet all of the relevant emission standards, for example, no matter how strict they happen to be. With their farm equipment, farming becomes as hassle-free as possible!

If you are concerned that environmental considerations mean that the sheer power of Kubota's agricultural machinery is diminished, then think again. The power output varies according to the particular model, of course. However, there is more than enough power to cope with even the most challenging of farm jobs. With the M 7001 model, for instance, power can go up to 170 hp with a 20 hp overpower when needed. This allows you to carry out all sorts of work safe in the knowledge that you will have enough power. Lastly, it is worth mentioning that the front tyres tractors are supplied with are particularly resistant to wear. They can withstand the physical constraints of soil in all sorts of states with ease.

The Comfort of a Kubota Tractor

Kubota offer tractors with cabins and those without them, too, so every type of customer is catered for. Either way, the the layout of the controls is convenient and designed with the driver in mind. Both the accessories and the dashboards of Kubota tractors allow for exceptional levels of comfort in all sorts of conditions. Operators who are inside a Kubota tractor cabin will feel it to be a luxurious working environment even if they are travelling over rough ground.

What’s more, Kubota's design engineers have thought about ease of use at every stage. This even comes down to the way other tools can be hitched up to their tractors with complete convenience. Features like fully opening bonnets, suspended pedals and hydrostatic steering mean that Kubota's agricultural tractor range really is a cut above the rest.
